Electrostatic Powder Coated Coils

Electrostatic powder coated panel is an environment-friendly panel manufactured by applying powder coating evenly onto metal sheets via electrostatic adsorption, followed by high-temperature curing. Compared with traditional painted panels, it is more durable and pollution-free, and widely used in construction and home appliance industries.

Eco-friendly & Pollution-free:
No formaldehyde or VOC emissions during production, with zero waste water and residues. It is safe for both the environment and human health.
Durable & Corrosion-resistant:
Featuring a dense coating, its acid and alkali resistance is 5 to 6 times that of traditional painted panels. It also boasts excellent salt spray resistance, ideal for harsh environments such as humid areas and chemical plants.
Superior Surface Quality:
The coating is full and even with a hardness up to 5H. It resists abrasion and scratches, and will not fade or chalk under long-term sunlight exposure. Its service life can reach 30 years.
Excellent Workability:
High flexibility ensures the coating remains crack-free after 180° bending (0T grade). It facilitates subsequent pressing and forming, and greatly improves production efficiency.

Powder Coating Performance Index

Item	Indicator data	Item	Indicator data
Coating thickness	20-100um	Slide test	0 grade
T bent test	0T-2T	Glossiness	±5°
Pencil hardness	≥5H	Boiling water experiment	≥4 Hours
Chromatic Aberration	≤0.5	Acid resistance test	≥720 Hours
MEK solvent friction	≥150 times	Alkali resistance test	≥240 Hours
Reverse impact	≥9 joules	Neutral salt spray resistance test	≥3600 Hours
Cupping test	≥6mm	UV aging test	≥2400 Hours

Application
It is widely applied in building curtain walls, home appliances & kitchen and bathroom products, chemical equipment, municipal facilities, storage racks, metal furniture, electrical control cabinets and more. It adapts to various complex working conditions including indoor & outdoor scenarios, highly corrosive and humid environments.
